General features
• SIM5320A：
Dual-Band UMTS/HSDPA 850/1900MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
• SIM5320(J)E：
Dual-Band UMTS/HSDPA 900/2100MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
• SIM5320J：
Dual-Band UMTS/HSDPA 850(800)/2100MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
• GPRS multi-slot class 12
• EDGE multi-slot class 12
• Output power
- UMTS 850/1900: 0.25W
- UMTS 900/2100: 0.25W
- GSM850/GSM900: 2W
- DCS1800/PCS1900: 1W
• Control Via AT Commands
• Supply voltage range: 3.4~ 4.2V
• Operation temperature: -30℃ to +80℃
• Extended operation temperature: -40℃ to +85℃
• Dimension: 30 * 30 * 2.9 mm
• Weight: 5.6g
Specifications for Data transfer
• HSDPA
- Max. 3.6Mbps(DL)
•WCDMA
- Max.384Kbps(DL), Max.384Kbps(UL)
• EDGE Class:
- Max. 236.8Kbps(DL),Max.118Kbps(UL)
• GPRS
- Max. 85.6Kbps(DL), Max.42.8Kbps(UL)
• CSD
- GSM data rate 14.4Kbps
- WCDMA data rate 57.6Kbps
- WCDMA 64kbps CSD for Video call
• Multi-PDP connect application
|
Other features
• USB Driver for Microsoft Windows2000/XP/Vista/7/8/10
• USB Driver for Windows CE/Mobile
• USB Driver for Linux /Android
• Firmware update via USB
• MMS
• TCP/IP
• MUX protocol over UART
• FTP/FTPS/HTTP/HTTPS/SMTP/DNS
• FOTA
Interfaces
• USB2.0
• UART
• SIM card
• SPI
• I2C
• Keypad
• Constant current sink
• GPIO
• RTC
• ADC
• Mic/Receiver **
• PCM **
Specifications for SMS
• Point to point MO and MT
• Text and PDU mode
Support embedded Script Language
• LUA Script Language
• Embedded AT *
Specifications for GPS/Location
• CELL assistant Location (No GPS)
• A-GPS: MS-Based, MS-Assisted
• Stand-alone GPS
• QUALCOMM XTRA GPS mode
|
Certifications
SIM5320A
• RoHS\REACH\RCM\FCC\
PTCRB\AT&T\IC\Rogers
SIM5320E
• RoHS\REACH\CCC\IMDA\RCM\CE(RED)\
GCF\Orange\TIM\Deutsche Telekom\Vodafone\ICASA
SIM5320J
• RoHS\REACH\JATE\Telec\Docomo\RCM
SIM5320JE
• RoHS\REACH\JATE\Telec\Softbank
Carrier Approvals
SIM5320A
• AT&T, Rogers
SIM5320E
• TIM, Orange, Vodafone
SIM5320J
• Docomo
SIM5320JE
• SoftBank
|
